Type | Communication | CIU Communication | Function | |
K212-01-PLC | PLC | / | Active , Reactive measurement | |
K212-02-PLC | PLC | / | Build in Relay, Shunt sampling | |
K212-03-PLC | PLC | / | Build in Relay, Shunt sampling, Neutral measurement |
|
K212-04-PLC | PLC | / | Build in Relay, Shunt sampling, Neutral measurement,Tariff,Event alarm |
|
K212-05-PLC | PLC | PLC/Bluetooth | Build in Relay, Shunt sampling, Neutral measurement,Tariff,Event alarm |
|
K212-06-RS485 | RS485 | / | Active , Reactive measurement | |
K212-07-RS485 | RS485 | / | Build in Relay, Shunt sampling, Neutral measurement,Tariff,Event alarm |
|
K212-08-Wifine | Wifine | Twisted Pair wire/RS485/RF | Different measurements way, Neutral measurement,Event alarm |
|
K212-09-Wifine | Wifine | Bluetooth | Different measurements way, Neutral measurement,Event alarm |
|
K212-10-Wifine | Wifine | Wifine/Bluetooth | Different measurements way, Neutral measurement,Event alarm |
|
K212-11-Wifine | Wifine | Bluetooth | Build in Relay, Event alarm |
Features
Voltage: 230V
Current: 5(80) A
Accuracy class: Class B / Active 1.0
Standard: IEC62052-11, IEC62053-21, IEC62055-41
Frequency: 50Hz
Impulse constant: 1000imp/kWh
Display: Without LCD
Power consumption: <10VA/2W
Starting current: 0.004Ib
Temperature range: -20~70℃
Flashing red: Impulse indication, width=80ms±20ms
Average humidity value of year: 75%
Maximal value: 95%
Cover: PBT+15%GF |
|
Base: PBT+15%GF |
|
Terminal cover: PBT+15%GF |
|
Hook: ABS |
Height 141.6mm Width 49mm Depth 87mm |
https://hqcdn.hqsmartcloud.com/ytl-e/2022/07/06/d114046&x829001sinlgephasekeypadsplitmeter20200813.pdf
