Residual current detection range:
|
5-6000mA |
Residual current setting value:
|
300-1000mA (can be set byour software according to actual needs) |
Temperature measurement range:
|
0°C -140°C |
Temperature alarm range:
|
45°C-140°C (can be set by our software according to actual needs) |
Measurement standard:
|
1.0 |
Residual current accuracy:
|
±1% |
Temperature accuracy:
|
±5% |
Residual current response time:
|
< 1s |
Temperature response time:
|
< 40s |
Power input range:
|
AC80-300V |
Maximum load current of relay:
|
80A |
Power consumption:
|
1W |
Communication:
|
RS485 |
Communication protocol:
|
Mod-BUS |
Communication rate:
|
1.2kbps-155.2kbps |
Operating temperature:
|
-10 ° C - 70 ° C |
Storage temperature:
|
-50 ° C - 80 ° C |
Use humidity:
|
0% - 90% without condensation |
Preservation humidity:
|
0% - 95% without condensation |
