Items |
Discription |
Supply power |
Single phase supply power |
Supply voltage |
220V±30% |
Frequency |
50Hz±10% |
Power comsumpion |
Static power consumption≤1W |
|
Dynamic power comsumpion≤1.5W |
Upgoing channel |
HPLC |
Control interface |
0~10V |
|
PWM |
Max load |
10A |
Relay work life |
100000 |
Work temperture |
-40~85℃ |
Work humidity |
10% ~ 100% |
Electro magnetic compatibility
|
Electrostatic discharge 8kV |
High frequency electromagnatic field 10V/m |
|
Fast transient pulse train 4kV |
|
Surge ≤1W |
Electric energy meters shall not be subjected to severe shock during transportation and storage, and shall be transported and stored in accordance with the provisions of gb13384-2008 general technical conditions of instrument packaging;
The energy meter should be stored in the original package, where the temperature range of the environment is 0-40c, the relative humidity should not exceed 85%, and there is no corrosive gas in the air.
Electricity meters shall be stored in the warehouse, and shall be placed on the platform. The stacked height shall not exceed 10 boxes. After unpacking, the stacked height of single packed electricity meters shall not exceed 5 layers.
Longth 127mm
Wideth 55mm
Hight 39mm
