Model | YTL380-50KS | YTL380-100KS | YTL480-200KS | YTL480-500KS |
Isolation method | Power frequency transformer isolation | |||
Way of working | Three-phase four-wire | |||
Rated DC input voltage(Vdc) | 380 | 380 | 480 | 480 |
Max input current | 132A | 260A | ||
DC input voltage range(Vdc) | 330Vdc~550Vdc | 420Vdc-580Vdc | ||
Rated AC output power(kW) | 50 | 100 | 200 | 500 |
Power harmonics THD | <3%(At rated power) | |||
Power factor | >0.8(At rated power) | |||
Max efficiency | 85% | |||
Rated output AC voltage(Vac) | 380Vac±2% | 380Vac±2% | 400Vac±2% | 400Vac±2% |
Rated output AC current(A) | 76A | 152A | 303A | 760A |
Rated output AC frequency(Hz) | 50Hz±1% | |||
Protective function | Input reverse connection protection, input undervoltage protection, input overvoltage protection, output overload protection, output short circuit protection, overheating protection | |||
Operating temperature | -10℃~+45℃ | |||
Relative humidity | 0-95% | |||
Cooling method | Air-cooled | |||
Dimensions(mm) | 650×1420×1365 | 650×1420×1365 | 1550×850×1880 | 2200×1000×2260 |
Protection level | IP20 |
Established in 2000, Zhejiang Yongtailong Electronic Co., Ltd. is located in the center of Shanghai, Hangzhou and Suzhou cities. YTL is a professional China Inverter 50kW 500kW Solar Off-Grid High Power Inverter Suppliers and Inverter 50kW 500kW Solar Off-Grid High Power Inverter Company. With more than 20 years of energy metering experience, we devote ourselves to providing competitive projects and creating value for customers. YTL was one of the first companies in the domestic market with which had an internal R&D department as well as international sales business. Since our foundation in 2000 we have grown to a manufacturer which complies and meet to many specifications from our national and international partners. At present our export volume makes us a leading company for technology and product export to more than 50 countries throughout the world. With provincial high-tech enterprise R&D center, YTL is the Top 100-enterprise with most investment value in Zhejiang. And“Yongtailong”is the famous brand of Zhejiang. For any new products of customers, we will communicate with customers very professionally, listen to their opinions and give useful suggestions to ensure that excellent quality products are made.
