Single Phase Smart Meter Supplier RS485 Modbus/DLT645 Suppliers
Single Phase Smart Meter Supplier RS485 Modbus/DLT645
Single-phase two-wire rail smart meter, can realize two-way communication through RS485 for reading and setting power data and parameters. The built-in high-quality magnetic holding relay can carry out user-side load management, and the backlight can be lit through the button to facilitate viewing data at night; The metering method can be set to meet the requirements of bidirectional measurement. The meter has multi-functions and compact structure, and is suitable for various application scenarios such as residential households, industrial fields, new energy charging stations, and renewable energy power generation.
- Type
- Functions
- Technical Parameters
- Connection Diagram
- Meter Dimensions
-
Type D11A015 D11A028 Communication RS485
Modbus and DLT645 protocalWi-fine
(Wi-Fine FAN/HAN) -
- RS485 Communication, Support Modbus and DLT645 protocal, Baud rate 9600\19200\38400\115200
- It can be setted 4 measurement modes, 1-total =forward、2-Total=reverse、3-Total =forward +reverse (default)、4-Total=Forward-Reverse
- Four tariff, 8 time period
- Neutral wire,with two-way unbalanced anti-tamper function
- Open cover detection, terminal cover detection through RS485 to send alarm with value and time; Store open detection events 10 times with time and date
- Designed with blue backlight by buttons, convenient for viewing power data at night
- Standard: IEC 62052-11 2020 \ IEC 62053-21 2020 \ EN50470-3 2022
-
D11A015 D51A012 Voltage AC 230V±20% AC 3×230/400V±20% Current 0.25~5(100)A 0.25~5(100)A Accuracy class Active1.0 reactive2.0 Active1.0 reactive2.0 Frequency 50-60Hz 50-60Hz Impulse constant 1000imp/kWh 1000imp/kvarh 1000imp/kWh 1000imp/kvarh Display: LCD 5+2 LCD 6+2 Power consumption ≤1W, 10VA ≤1W, 10VA Starting current 0.4%Ib 0.4%Ib Temperature range -40～70℃ -40～70℃ Average humidity value of year 75% 75% Maximal value 95% 95% -
-
